Automatic Liquid Filling Machine — Multi-Head Piston Filler

Name: Automatic Liquid Filling Machine — Multi-Head Piston Filler
Brand: New Vision Machines
SKU: bzomM7QIErvvUytYB6gb
Price: 85000 INR
Availability: InStock

An automatic liquid filling machine is a multi-head piston-driven or flow-meter-based filler that dispenses precise volumes of liquid — from thin water-like products to viscous edible oils and syrups — into bottles, jars, and containers at speeds of 10–40 bottles per minute depending on fill volume and viscosity. The multi-head configuration fills 2, 4, or 8 bottles simultaneously per cycle, multiplying output over a single nozzle filler at the same cycle rate. The machine operates by drawing liquid from a stainless steel holding tank through the piston cylinders, which dispense a set volume per stroke into the waiting bottles below. Fill volume is adjusted via the piston stroke length, and fill accuracy is typically ±1–3ml depending on liquid viscosity. SS304 contact surfaces ensure food and pharmaceutical compliance. A drip tray below the nozzles catches any inter-cycle drip, keeping the work area and container exteriors clean. In India, liquid filling machines are used in edible oil repackaging units in Gujarat and Rajasthan, mineral water plants across India's FMCG belt, pharma syrup manufacturers in Hyderabad and Baddi, juice and beverage companies in Maharashtra and Karnataka, and cosmetic liquid producers in Mumbai and Delhi. Fill volumes from 100ml to 5 litres are the typical Indian food and pharma packaging range. New Vision Machines supplies liquid filling machines with on-site installation, nozzle selection for your liquid's viscosity, and fill accuracy calibration at your target volume. NVM's engineering team has matched filling machines to a wide range of Indian liquids from thin coconut water to thick honey — the right nozzle diameter and piston diameter are selected before delivery. At ₹85,000 for a standard multi-head liquid filler, payback typically comes within 6–10 months for operations currently using manual filling with ladles or single-nozzle semi-automatic units — the accuracy improvement, speed gain, and labor displacement make the investment straightforward for any Indian liquid FMCG or pharma operation.

Starting from

₹85,000₹99,000Save 14%

Excluding GST · GST Invoice Available

Buy Now

Call Now Ask a Question

No spam · Response in 10 min · Free consultation

Genuine Product

Pan-India Delivery

Warranty Support

Installation Help

Technical Specifications

Machine Type	Automatic Multi-Head Piston Liquid Filling Machine
Automation Grade	Fully Automatic / Semi-Automatic
Number of Heads	2, 4, or 8 (configuration dependent)
Fill Volume Range	50ml to 5000ml (adjustable per head)
Filling Accuracy	±1–3ml
Output Speed	10–40 bottles per minute
Material of Construction	SS304 Liquid Contact Parts

Drip Prevention	Anti-Drip Nozzle + Drip Tray
Power Supply	220V, 50Hz, Single Phase
Suitable For	Edible oil, water, juice, syrup, pharma liquid, cosmetic liquid
Country of Origin	India / China (verify with supplier)
Warranty	Not specified — verify with supplier
HSN Code	Not specified — verify with supplier

About this product

Product details

CategoryAutomation

Product IDNVM-AUTOM-BZOM

AvailabilityIn Stock — Ready to Ship

Warranty1 Year Manufacturer Warranty

ShippingPan-India Delivery

Frequently Asked Questions

Common questions about the Automatic Liquid Filling Machine — Multi-Head Piston Filler

What is an automatic liquid filling machine and what liquids can it fill?

An automatic liquid filling machine is a piston or flow-meter-based filler that dispenses precise volumes of liquid into bottles and containers at controlled speed. In India, it fills edible oil, mineral water, juice, pharmaceutical syrups, cosmetic liquids, and chemical solutions in fill volumes from 50ml to 5 litres per bottle.

How much does an automatic liquid filling machine cost in India?

Automatic liquid filling machines in India are priced from ₹75,000 for basic 2-head units to ₹5,00,000 for high-speed 8-head configurations. New Vision Machines supplies multi-head liquid fillers starting at ₹85,000 with nozzle selection and fill accuracy calibration included.

Which liquid filling machine is best for edible oil and juice in India?

For edible oil and juice filling in 200ml–5-litre bottles, a multi-head piston liquid filling machine with SS304 contact parts, anti-drip nozzles, and adjustable fill volume per head is the right specification. The nozzle diameter must match the oil or juice viscosity — New Vision Machines selects the right nozzle type for your specific product.

What is the output speed of an automatic liquid filling machine?

A multi-head automatic liquid filling machine fills 10–40 bottles per minute depending on fill volume per bottle and number of filling heads. A 4-head machine filling 500ml bottles typically runs 15–20 bottles per minute per head, or 60–80 bottles per minute total.

Which company supplies liquid filling machines in Ahmedabad and Mumbai?

New Vision Machines supplies automatic liquid filling machines in Ahmedabad, Mumbai, Indore, Hyderabad, and pan-India. NVM provides on-site installation with fill accuracy calibration at your target fill volume and viscosity.

Piston liquid filler vs flow-meter filler — which to choose?

Choose a piston liquid filling machine for viscous liquids like edible oil, honey, thick syrups, and creams where volume dispensing is reliable. Choose a flow-meter filler for low-viscosity liquids like water, juice, and thin pharma solutions where flow rate measurement gives better speed and accuracy at high output.

What features should I check when buying a liquid filling machine?

When buying a liquid filling machine, verify the fill volume range and accuracy specification, number of filling heads, nozzle anti-drip design, contact surface material (SS304 mandatory for food and pharma), and whether the supplier calibrates the machine to your specific liquid's viscosity before delivery. New Vision Machines performs a fill accuracy test on your actual liquid before machine handover.
